280 results about "Image reconstruction algorithm" patented technology

A system for optical imaging of a thick specimen that permits rapid acquisition of data necessary for tomographic reconstruction of the three-dimensional (3D) image. One method involves the scanning of the focal plane of an imaging system and integrating the range of focal planes onto a detector. The focal plane of an optical imaging system is scanned along the axis perpendicular to said plane through the thickness of a specimen during a single detector exposure. Secondly, methods for reducing light scatter when using illumination point sources are presented. Both approaches yield shadowgrams. This process is repeated from multiple perspectives, either in series using a single illumination / detection subsystem, or in parallel using several illumination / detection subsystems. A set of pseudo-projections is generated, which are input to a three dimensional tomographic image reconstruction algorithm.

An apparatus, system and method for providing an image enhancing effect for a photographic image of a target region within an intravascular environment. The image enhancing effects may be a physical process based upon the nature of the detected light or based upon different aspects of expected light reflection behavior, for example, by running predefined image reconstruction algorithms. The apparatus has a plurality of different embodiments, each of which reduces the ambient “noise” detected along with the light reflected from the target region in order to increase the signal / noise ratio, thereby to enhance the quality of the image produced.

An imaging system includes a source and a detector that can be quickly and easily moved out of the way after scanning. During scanning, the actual paths that the source and detector travel are tracked, such as by an associated surgical navigation system tracking system. The actual locations of the source and detector during each x-ray image are used in the image reconstruction algorithm. Since the actual locations are used in the algorithm, the locations do not have to be as precisely controlled. In one embodiment, the source and detector are mounted proximate outer ends of first and second c-arm sections. The first and second c-arm sections are extendable to form a complete c-arm and retractable to a collapsed position when not in use. In the disclosed embodiment, the c-arm sections are mounted to a base or carriage under the patient support surface (such as the surgical table).

A method for imaging objects in a highly scattering turbid medium comprises: using a group of sources and detectors to generate a plurality of emergent energy waves from the medium, determining the intensity data of the emergent energy waves and processing the intensity data by using an image reconstruction algorithm. Arrangement of sources-detectors may be in parallel (transmission and / or backscattering) geometry or in cylinder geometry. The reconstruction algorithm is a novel hybrid dual Fourier tomographic algorithm for a fast 3D image reconstruction. The forward models are the radiative transfer model based on the cumulant solution of the radiative transfer equation or the diffusion model based on the approximate diffusion equation.

An image reconstruction algorithm begins with an initial acquisition of a preoperative imaging volume followed by a second imaging sequence subsequent to an applied deformation. A computational domain (model) is generated from the preoperative image series and boundary conditions are derived from a pre-post deformation comparison, as well as from information gathered from deformation source application (i.e., displacement and / or force). Using boundary conditions, a series of model-based image deformations is accomplished while varying model material properties. A calculation of a Jacobian matrix relating the change in regional mutual information is performed with respect to the change in material properties. Upon completion of this process, matrix regularization techniques are used to condition the system of equations and allow for inversion and subsequent delivery of model-property adjustments.

A method based on capacitance chromatographic imaging system for measuring the two-phase oil-gas stream features that a reverse projection algorithm is used to reconfigure the oil-gas stream's medium distribution image to real-time show the stream type in pipeline, a fuzzy pattern recognization is used for in-line automatic recognization of stream type, a combined image rebuilding algorithm is used to rebuild the image for showing oil and gas distribution, and the image is processed to obtain the porosity of the oil-gas stream. Its equipment is composed of array-type capacitance sensor, data acquisition unit and computer. Its advantages are high speed and high precision.

Image reconstruction approaches that use standard Cartesian-sampled, frequency-domain SAR data, which can be collected by a platform with a single radar antenna, together with its associated metadata as the input and generate an output comprised of a set of images that show the directions of moving targets, estimates of their motions, and focused images of these moving targets.

The present invention provides a non-contact impedance sensor which is mounted on measuring region, the radial section structure of the sensor comprises of four layers, metal tube layer, insulation material layer, electrode array layer and insulation ring layer from outside to inside in turn. At least two electrodes are distributed in one circle on the insulation ring layer whose thickness is less than 1% of external diameter, and electric field intensity between electrode array and metal tube layer is less than breakdown strength of insulation layer. The electrode array is separated with measuring region by insulation ring layer. Two image reconstruction algorithms to realize electrical impedance tomography based on the said sensor are also provided. The present invention provides analytical medel, corresponding sensitivity distribution expression and two rapid imaging methods, the sensor can measuring synchronous same-positional dual-mode impedance, advance mutual fusion of real parts and imaginary part information of impedance distribution, predigest the design and implement of software and hardware of dual-mode measuring system.

A line scan cone beam CT imaging system irradiates an object with an x-ray cone beam for multiple views. A projection data set of the object is acquired at each view. Between views, the cone beam and detector array are translated along parallel lines in opposite directions. An image is generated by converting the cone beam projection data set of the real object into a parallel-beam projection data set corresponding to a virtual object and using a total variation minimization image reconstruction algorithm to reconstruct a virtual image of the virtual object. The reconstruction algorithm includes the constraint that the Fourier transform of the reconstructed virtual image matches the known Fourier coefficients in the set of converted parallel-beam projections of the virtual object. The constructed virtual image is then transformed into an image of the real object.

The invention discloses a structure illumination super-resolution microscopy imaging system and an imaging method thereof. The imaging system comprises an illumination light source, a rotating structure light generator, a first convergent lens, a light splitter, an objective lens, an object stage, a sample, a second convergent lens, a digital imaging device and a computer. An original image is processed through an imaging image reconstruction algorithm; super-resolution can be achieved only by rotating structured light stripes for four times without phase displacement; the imaging image reconstruction algorithm is based on frequency domain processing instead of non-spatial domain processing; a spectrum process of a super-resolution image of a sample is different from a traditional frequency domain method, structured light directions are not analyzed one by one and all directions are merged for analysis; in order to obtain traditional uniform 2-fold resolution improvement in various directions, the theoretical quantity of original images can be reduced to 4 from 9 of a traditional method; the quantity of the original images is further reduced to 3 and uniform 1.5fold resolution improvement in various direction can be theoretically obtained.

The invention discloses a method of dose reversal of the target of a patient in radiotherapy, the method makes use of a light source and a flat panel detector to carry out the rotary scanning around the target of the patient, so as to obtain the data of the target image of the patient and the dose data which penetrates the target of the patient; the invention applies a virtual PI line reconstruction algorithm to carry out the reconstruction and processing, and the treatment is carried out by adjusting the position of the patient and the input dose distribution data according to the processing results. As the invention adopts a true three-dimensional image reconstruction algorithm which is based on the flat panel detector, the spatial resolution of the true three-dimensional image is isotropic, the invention does not need interpolation, and can directly realize the processing of the image on the three-dimensional space, thus greatly improving the imaging precision and solving the problem that the imaging is not precise due to the interpolation error during the integration process into a quasi three-dimensional image of the existing radiotherapy, which can further affect the accurate implementation of the treatment plan of focus.

The invention provides an algorism of magnetic resonance imaging fast and generalized self-aligning and collecting image for reconstructing, which combines the data fitting and channel merging to one step linear operation, the parameter of which can be counted out in advance and stored, which can increase the image reconstructing speed greatly, and solve the problem of long reconstructing time in current GRAPPA algorism; the algorism can also compare the image signal-to-noise ratio loss caused by different reconstructing method base on image domain and frequency domain by using weighting matrix.

The invention relates to a CT image reconstruction method based on GPU hardware acceleration, which belongs to the field of X-ray CT technology. The software portion of the invention generally comprises a GPU-based CT data preprocessing module, a GPU-based CT data filter module, a GPU-based CT orthogonal protection module, and a GPU-based CT image reconstruction and back projection module. The method can achieve acceleration of CT image reconstruction algorithm by using GPU hardware, and the reconstructed portion and the data processing portion are achieved on GPU. The invention provides a segmentation processing method used for processing larger data, which aims to solve the prior problems of insufficient display memory of GPU and low data transmission speed from memory to the display memory. Different from prior methods, the segmentation processing method only needs a portion of projection data desired for each segment to be reconstructed, thus reducing data transmission and improving the entire reconstruction speed.

A Compressed Sensing (CS) based image reconstruction method and system is described herein which may be used to reduce the X-ray dose radiation in Computed Tomography (CT) or to decrease the scan duration in MR imaging (MRI). Methods and systems described herein may address problems that have hindered the clinical usage of CS, i.e. computation complexity and modeling problems. Using the described algorithm, high quality images may be recovered from undersampled data which may help to reduce the scan time and the exposed invasive radiations. Using the same set of data in conventional image reconstruction algorithms (e.g. Filtered Back Projection (FBP) in CT) may cause severe streak artifacts and may take significantly more time using Graphics Processing Units (GPU) and parallel clusters with the conventional CS-based methods. This method can be used other imaging modalities using Radon transform (such as C-Arm and electron tomography, for example).

The invention discloses an automatic positioning method of the target of a patient in radiotherapy, the method makes use of a light source and a flat panel detector to carry out the rotary scanning around the target of the patient, so as to obtain the image data of the target of the patient; the invention applies a virtual PI line reconstruction algorithm to carry out the reconstruction and processing on data to obtain the image of the target of the patient; and the treatment is carried out by comparison results of the input image data and the adjustment of the position of the patient. As the invention adopts a true three-dimensional image reconstruction algorithm which is based on the flat panel detector, the spatial resolution of the true three-dimensional image is isotropic, the invention does not need the interpolation, and can directly realize the processing of the image on the three-dimensional space, thus greatly improving the imaging accuracy and precision and solving the problem that the imaging is not precise due to the interpolation error during the integration process into a quasi three-dimensional image when in automatic positioning of the target of the patient of the existing radiotherapy, and the problem can further affect the precise positioning of focus and the accurate implementation of the treatment plan.

An optical IR touch sensing apparatus can determine, based on output signals of light detectors, a light energy value for each light path across a touch surface, and generate a transmission value for each light path based on the light energy value. A processor can operate an image reconstruction algorithm on at least part of the thus-generated transmission values and determine a position of a touching object on the touch surface, an attenuation value corresponding to the attenuation of the light resulting from the object touching the touch surface, and an occlusion compensation value for compensating the occlusion affect from other objects on the touch surface. Using these values, the processor can identify the type of object.

In the present invention, the fast high-resolution image reconstruction of PET projection data is realized by introducing the organic combination of super-laxation speeding factor and variable background constraint, the reconstruction speed and spatial resolution are superior to available ordered subset expectation maximum (OSEM) process, and the antijamming capacity is superior to traditional filtering back projection (FBP) process. The present invention is the improvement of OSEM, and said algorithm combines several kinds of data processing technology in the reconstruction of the heat source image to obtain reconstructed image with high spatial resolution and low noise.

An optical imaging method using a single-pixel detector. An image of a target object is expressed by using discrete pixels, and the size of the image is M×N pixels. A cosine structured light field generator is used for generating a series of light fields that have different frequencies and are distributed according to cosine, wherein each set of frequencies corresponds to at least three different initial phase φ values; the light fields with cosine distribution that have different frequencies and different initial phases are used to sequentially irradiate the target object; an optical detector (2) is used for sequentially receiving light intensity signals from the target object and then response values of the optical detector (2) are sequentially collected and recorded; An image reconstruction algorithm is established on the basis of the light fields, the number of measurements can be greatly reduced, and a high-quality reconstructed image can be obtained.

An imaging system includes a source and a detector that can be quickly and easily moved out of the way after scanning. During scanning, the actual paths that the source and detector travel are tracked, such as by an associated surgical navigation system tracking system. The actual locations of the source and detector during each x-ray image are used in the image reconstruction algorithm. Since the actual locations are used in the algorithm, the locations do not have to be as precisely controlled. In one embodiment, the source and detector are mounted proximate outer ends of first and second c-arm sections. The first and second c-arm sections are extendable to form a complete c-arm and retractable to a collapsed position when not in use. In the disclosed embodiment, the c-arm sections are mounted to a base or carriage under the patient support surface (such as the surgical table).

The invention belongs to the thermoacoustic imaging technology field, in particular to an image reconstruction algorithm of the sound velocity uneven medium thermoacoustic imaging. The method modifies the time domain reconstruction method of the sound velocity uneven medium thermoacuostic imaging, which leads to that the propagation time of acoustic waves between two points in medium is no longer proportional to the distance and is worked out through the estimated sound velocity distribution. Currently, the prior knowledge of the sound velocity distribution is mostly required by the reconstruction algorithm on the sound velocity uneven medium thermoacuostic imaging. And an iterative method is adopted for the calculation and the speed is slow. The invention does not require the prior knowledge of the sound velocity distribution in the medium and is a direct inverse approach. The invention can rapidly reconstruct a whole thermoacoustic image.

Methods, systems and processes for providing efficient, accurate and exact image reconstruction using portable and easy to use C-arm scanning devices and rotating gantries, and the like. The invention can provide exact convolution-based filtered back projection (FBP) image reconstruction by combining a curved scan of the object and a line scan of the object. The curved scan can be done before or after the line scan. The curved scan can be less than or greater than a full circle about an object being scanned.

The invention provides an image fusion method based on compressed sensing. The image fusion method includes the three steps of image collection, observed value fusion and image reconstruction. According to the image collection, an image to be fused is divided into image blocks, according to the observed value fusion, a double-channel pulse coupling neural network model is adopted for performing primary image fusion, and a weighted average method is adopted for performing fine fusion on observed values, and finally a final image fusion result is obtained through an image reconstruction algorithm. In the sampling step, characteristics of the image self to be fused are fully considered, and detail information of the result obtained through the fusion is improved; a partitioning compression method is adopted, the partitioned images are sampled and compressed at the same time at a sampling terminal, and complexity, caused by sparse processing performed in advance, of a traditional compressed sensing sampling terminal is avoided; the reconstruction algorithm is high in reconstruction speed and robustness.

The present invention proposes a fast GeneRalized Autocalibrating Partially Parallel Acquisition (GRAPPA) image reconstruction algorithm for magnetic resonance imaging. The algorithm simplifies data fitting and channel merging in the process of reconstruction into a one-step linear calculation. Parameters needed to perform the linear calculation step can be pre-calculated and stored, thereby greatly increasing the image reconstruction speed and solving the problem of the relatively long image reconstruction time needed by prior art GRAPPA algorithms. Also, the algorithm can employ a weighting matrix to conveniently compare signal-to-noise ratio losses of images brought by different types of reconstruction methods in image domain and frequency domain.

The invention relates to a PXI-bus-based respiration process three-dimensional electrical impedance imaging system and an imaging method thereof. According to the PXI-bus-based respiration process three-dimensional electrical impedance imaging system and the imaging method thereof, the three-dimensional electrical impedance imaging system which is in three layers and comprises 48 electrodes is constructed by means of highly integrated hardware and software tool kits of the PXI bus; a pair of adjacent exciting electrodes is selected sequentially through a gating switch; safe alternating currents are injected into a thoracic cavity, voltage signals on the other electrodes are collected synchronously; a distribution image of sensitive areas of electrical impedances inside the thoracic cavity during a respiration process is obtained on a computer through filtration, amplification, analog-digital conversion, demodulation and transmission and finally through an image reconstruction algorithm. Compared with the existing electric resistance imaging system, the PXI-bus-based respiration process three-dimensional electrical impedance imaging system has the advantages of being high in measuring accuracy, rapid in speed and high in reliability, having no damage to human bodies, achieving continuous real-time bedside monitoring and continuously monitoring respiration variations of human lungs clinically in real time.

The invention belongs to the technical field of radar, and discloses a multiple-input multiple-output array radar staring imaging method based on tensor compression perception. The method includes the steps of configuring a transmit-receive array, setting each emission array element in the emission array to emit random frequency hopping signals, setting the referential array element position coordinate of the array, the transmit-receive array and the coordinates of a target scene, establishing a signal reception model of a radar reception array in a same range gate, matching and filtering the reception data, converting the problem of restoring the scattering coefficient of a single-range gate into solving sparse optimization, reconstructing the target scene in the single-range gate for the sparse optimization of signal reception model by using an improved 2D-SL0 high-efficient rapid imaging method, reconstructing the scattering coefficient matrix in each range gate by using the rapid image reconstruction algorithm, and finally obtaining the multi-range gate target scene image. The algorithm complexity is reduced, the image reconstruction time is shortened, and rapid imaging of non-sparse large scene object is realized.

The invention discloses a compressed sensing magnetic resonance imaging method controlled by a radio-frequency pulse, and relates to the magnetic resonance imaging method. The invention provides the compressed sensing magnetic resonance imaging method controlled by the radio-frequency pulse, wherein the compressed sensing magnetic resonance imaging method controlled by the radio-frequency pulse is capable of controlling a space K to spread spectrum easily. The method includes the spectrum spreading to the space K from the radio-frequency pulse, undersampling at random and image reconstruction. In the magnetic resonance imaging, the radio-frequency pulse of linear frequency modulation is exerted along the phase encoding direction to control the energy diffusion of magnetic resonance imaging data space. The undersampling at random is carried out to the imaging data with spread spectrum, and sampling time is reduced. In terms of the undersampling data, suggested fast reconstruction algorithm is adopted to carry out sparse reconstruction to the imaging. Due to the fact that radio-frequency pulse sequence is utilized to carry out the spread spectrum of the space K, compared with space K with a shim coil, the controllable property of the spread spectrum of the space K is good. The purposes of reducing imaging time and accelerating the magnetic resonance imaging are achieved by adopting the methods of undersamping the magnetic resonance signal at random and the image reconstruction algorithm.

The invention brings forward a method and device for measuring two-dimensional angle distribution of the radiation dose rate of a radioactive substance. The method comprises: a gamma camera detecting gamma photons incident from each direction of a defining object angle plane in an object area, and respectively recombining to form projection data and power spectrum data; reconstructing the projection data by use of an image reconstruction algorithm to obtain a radiation gamma image; based on this, obtaining the two-dimensional angle distribution of the fluence rate of the gamma photons incident from each direction in the object area; and according to incident photon energy, searching for corresponding conversion coefficients, and by use of the conversion coefficients, converting the two-dimensional angle distribution of the fluence rate of the gamma photons into the two-dimensional angle distribution of the dose rate of radiation of the radioactive substance to the position of the gamma camera. The measuring method provided by the invention realizes measurement of the two-dimensional angle distribution of the radiation dose rate of the gamma photons incident from the different directions in the object area by use of such devices as the gamma camera and the like.

The invention relates to a method of imaging an interior of a turbid medium, a device for imaging an interior of a turbid medium, and a medical image acquisition device. A turbid medium is accommodated in a receiving volume (5), light from a light source is coupled into (10) and out of the receiving volume and detected (15) after which a dataset is obtained from the detected light (20). The dataset is then communicated to an image reconstruction algorithm (30) and an image of an interior of the turbid medium is reconstructed based on the detected light (35). According to the invention the dataset is changed prior to communicating the dataset to the image reconstruction algorithm into a further dataset (25), with a further dataset satisfying an input assumption underlying the image reconstruction algorithm.

Methods, systems and processes for providing efficient, accurate and exact image reconstruction using portable and easy to use C-arm scanning devices and rotating gantries, and the like, that combines both a circle and a curve scan. The invention can provide exact convolution-based filtered back projection (FBP) image reconstruction by combining two curved scans of the object. The curved scan can be less than or greater than a full circle about an object being scanned. The invention can be done by a first curve within a first plane followed by a second curve within a second plane that is transversal to the first plane.
